COMBI PLATE FEATURES
● Incorporate a plate washer attached to a standard strata plate to give a superior product with enhanced performance.
● Designed with a profile that gives greater strength by strategically pressing the vees, placing the perimeter of plate in tension
● Has “user friendly” rounded corners
● Allows faster installation by eliminating the handling of two separate components
● Can be facilitate flat and domed plates (up to 150mm square) to increase rock surface coverage area
● Can be utilised with lighter domed or flat plates to provide an economic advantage over heavier
● Is suitable for direct placement onto the rock surface or used against welded mesh
● Are supplied with a slot for suspension of light services and some domed plates include a services support lug
COMBI PLATE SPECIFICATION
| Code | Bottom Plate | Top Plate | Hole Dia. | Combination | ||||||||
| Size | Finish | Size | Finish | |||||||||
| CP-150-15B | 280x300x1.5 | black | 150x150x4 | black | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-15G | 280x300x1.5 | Pre-Galv | 150x150x4 | HDG | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-15D | 280x300x1.5 | HDG | 150x150x4 | HDG | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-16B | 280x300x1.6 | black | 150x150x4 | black | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-16D | 280x300x1.6 | HDG | 150x150x4 | HDG | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-19B | 280x300x1.9 | black | 150x150x4 | black | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-19D | 280x300x1.9 | HDG | 150x150x4 | HDG | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-20B | 280x300x2.0 | black | 150x150x4 | black | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-20G | 280x300x2.0 | Pre-Galv | 150x150x4 | HDG | 36, 42, 49 | Pressing / Welding | ||||||
| CP-150-20D | 280x300x2.0 | HDG | 150x150x4 | HDG | 36, 42, 49 | Pressing / Welding | ||||||
